规格型号

Specification model

DP-YK-06

DP-YK-10

DP-YK-20

DP08877

DP-YK-50

DP-YK-60

DP-YK-80

DP-YK-100

DP-YK-120

DP-YK-150

DP-YFK-200

DP-YK-250

DP088770

DP-YK-400

DP-YK-500

标准制冷量 Standard refrigeration quantity

50HZ

60HZ

Kcal/h

1290
1514

2382
2786

4541
5315

6803
7955

11094
13235

13091
15901

19746
23521

22188
26478

25146
29661

35652
42162

44230
52064

50293
59314

67304
80324

91461
109168

115498
138460

50HZ

60HZ

KW

1.5
1.76

2.77
3.24

5.28
6.18

7.91
9.25

12.9
15.39

15.22
18.49

22.96
27.35

25.81
30.79

29.24
34.49

41.33
48.7

51.43
60.54

58.48
68.97

78.26
99.4

106.35
126.94

134.3
161

输入总功率
Total power inpu

KW

1.01

1.34

2.27

3.33

5.8

6.33

9.25

10.15

11.58

16.6

21

23.8

33.2

44.4

56

电 源
Power source

1PH ～ 220V 50HZ （ 60HZ ）

3PH ～ 380V 50HZ (200V/220V/415V 50HZ/60HZ)

(110V 50HZ/60HZ)

制冷剂 Refrigerant

名称
Name

R22 (R 134a / 407c )

控制方式
Control mode

毛细管
Capillary vessel

外平衡式热力膨胀阀
Outside balance -like thermal energy expansion valve

压缩机

Compressor

类型

Type

全封闭旋转式

Entire seal rotary system

全封闭涡旋式（活塞式）

Entire seal vortex type (plunger type)

功率

Power

KW

0.59

0.89

1.77

2.8

4.66

5.2

7.95

8.85

9.98

7.2*2

8.85*2

9.98*2

13.62*2

18.78* ２

23.6*2

冷凝器 Condenser

类型

Type

高效紫铜管套铝翅片式 + 低噪音外转子风机
The high-effect red copper pipe box aluminium wing slices dyadic + low noise outside rotator wind machine

冷却风量 Cooling amount of wind

m 3 /h

750

1000

2000

3000

5000

6000

8000

10000

12000

15000

20000

25000

30000

40000

50000

蒸发器 Evaporator

类型

Type

水箱盘管（板式）

Water tank plate tube (beat)

冷冻水量 Freezing water volume

m 3

0.258
0.303

0.476
0.557

0.908
1.063

1.36
1.59

2.22
2.65

2.60
3.20

3.95
4.7

4.52
5.31

5.03
5.93

7.23
8.43

8.84
10.41

10.06
11.86

13.46
16.06

18.29
21.83

23.1
27.69

水箱容量 Water tank capacity

L

16

20

40

50

70

70

120

200

200

270

350

350

420

550

600

进出水管径 Turnover water caliber

inch

1/2"

1/2"

1/2"

1"

1"

1"

1"

1-1/2"

1-1/2"

2"

2"

2-1/2"

2-1/2"

3"

3 ″

水泵

Water pump

功率

Power

kw

0.37

0.37

0.37

0.37

0.75

0.75

0.75

0.75

1.1

1.5

2.25

2.25

3.75

3.75

5.5

扬程

Lift

m

25

25

25

20

25

25

25

20

25

25

25

20

25

20

25

安全保护

Safekeeping of security

压缩机过热保护，过流保护，超温保护，流量保护，相序 / 缺相保护，排气过热保护 , 防冻保护
The compressor excessively hot protection, has flowed the protection,the height pressure protection, the ultra warm protection, the currentcapacity protection, the foreword/lacks protects, has exhausted thehot protection, frostproof protection

机械尺寸 Mechanical size

长

Long

mm

500

500

580

930

1140

1140

1310

1680

1680

1800

2000

2000

2200

2500

2980

宽

Width

mm

500

500

550

520

560

560

720

810

810

990

1130

1130

1130

1500

1700

高

High

mm

725

725

925

975

1040

1040

1270

1280

1280

1680

1720

1914

2026

2250

2300

机械重量

Mechanical weight

Kg

50

73

100

135

175

180

320

450

530

750

835

920

1080

1125

1250
